Symbol MC1000

add to favorites

details:

» home » Symbol » Symbol MC1000

Title:

Symbol MC1000

Brand:

Symbol

Manufacturer:

Symbol Technologies

Release-Date:

October, 2004

Dimensions-width-x-height-x-depth:

64.5 x 163 x 38 millimetres
2.5 x 6.4 x 1.5 inches

Bounding-Volume:

399.5 cubecentimetres

Mass:

205 grams (battery included)

Embedded-Operating-System:

Microsoft Windows CE .NET 4.2 Core (McKendric)

Operating-System-Kernel:

Microsoft Windows CE 4.2

CPU:

Intel XScale PXA270

CPU-Clock:

312MHz

Databus-Width:

32bit

CPU-Core:

Intel XScale

Number-of-Transistors:

Level-1-cache:

32KB data cache / 32KB instruction cache

Instruction-set:

ARM v5TE

ROM-capacity:

32MB

RAM-type:

SDRAM

RAM-capacity:

32MB

Expansion-Slots:

MMC, SD, SDIO

Display:

monochrome transflective TFT

Color-Depth:

4bit/pixel (16 scales)

Resolution:

240 x 240 (57600 pixel)

Diagonal:

2.2` (56 millimetres)

Viewable-size:

1.6` x 1.6` (39.6 x 39.6 millimetres)

Dot-Pitch:

0.165 millimetre/pixel

Graphical-Controller:

D-A-converter:

Audio-Input:

Number-of-speakers:

1 (mono)

Audio-Output:

Not supported

Supported-Cellular-Networks:

Supported-Data-Standards:

Ring:

UART:

RS-232, 115200bit/s

Universal-Serial-Bus:

USB 1.1 client, 12Mbit/sProprietary connector

Infrared-Gate:

Not supported

Bluetooth:

Not supported

LAN:

Not supported

Wireless-LAN:

Not supported

Modem:

Not supported

Control-Peripherals:

Positioning-Device:

Not supported

Keyboard:

alphanumeric phone keyboard, 21 keys

Directional-Pad:

5-way directional block

Battery:

Lithium-ion, removable

Battery-Capacity:

1800mAh

Avarege-Current:

60 mA

Estimated-Battery-Life:

30 hours

Additional-Features:

dust resistant drop resistant (1.2m) water resistant IP54 standard integrated bar code scanner
